· GUNT-150iTD turning and milling compound CNC system is an upgrade of software and hardware on the basis of the previous generation. The high-performance processor enables fast data operation, higher real-time performance, high system stability, stronger control functions, simple operation, and absolute configuration. The value encoder realizes high-speed and high-precision control.
· Number of controlled axes: 2-5 axes + 1 spindle
· The number of linkage axes: linear 2 to 5 axes, arc 2 axes
· Industrial-grade 32-bit processor, clocked at 1GHz
· User storage space 100M
· Interpolation period 2ms
· Minimum control accuracy: 1um, maximum speed: 240M/min
· Display resolution: 800X600, 8-inch TFT display
